Osma Board pro Moisture resistant plasterboard Type H

Moisture  Resistant Gypsum boards ideal for construction in areas with high humidity and exposure to moisture.

Dimensions:

  1. 5 x 2400x1200 mm
  2. 5 x3000x1200 mm
  3. 15 x 2400x1200 mm
  4. 15 x3000x1200 mm



Usages

  • Osma board Gypsum Boards are used for cladding areas with exposure to humidity and moisture.
  • Drywall partitions Using metal frames in kitchens and bathrooms
  • Partitions with ceramic tiles finish
  • wall linings and furring in kitchens and bathrooms
  • Partitions in any areas exposed to moisture or humidity

Properties:

  • lightweight constructions
  • "easy, fast and dry application "
  • good sound insulation performance compared to other lightweight construction material
  • Good fire protection performance
  • high resistance to absorption of moist

                                                Board dimension:

                                                "Thickness:  12.5 , 15 mm"± 0.5

                                                Width: 1200 mm

                                                "Length: 2400, 2800, 3000 mm"

                                                * Special sizes are available upon request

                                                Board Weight (average value):





                                                12.5mm ≈ __≥8.5____ kg/m2

                                                15mm ≈ ___≥10.2____ kg/m2

                                                Density: ≥ 680 kg/m3

                                                Flame Spread Index :

                                                According to DIN 18180 Specifications

                                                Surface Water Absorption ≤ ___1.6___ %

                                                Water Resistance  ≤ ___5___ %

                                                Nail Pull Resistance ≈  120 lbf

                                                Edge Details:

                                                Square Edge

                                                Tapered Edge

                                                Appearance:

                                                Green paper liner

                                                Store on pallets in a dry warehouse

                                                Osma board Pro Type H1 12.5 x 1200x2400 = 60 pcs/pallet                                                                                                      Osma board Pro Type H1 12.5 x 1200x2800 = 60 pcs/pallet

                                                Osma board Pro Type H1 12.5 x 1200x3000 = 60 pcs/pallet

                                                Osma board Pro Type H1 15 x 1200x3000 = 60 pcs/pallet

                                                Osma board Pro Type H1 15 x 1200x2400 = 60 pcs/pallet

                                                Osma board Pro Type H1 15 x 1200x2800 = 60 pcs/pallet

                                                Osma board Pro Type H1 15 x 1200x3000 = 60 pcs/pallet

                                                Board Type

                                                DIN 18180

EN 520

                                                ES 2002/2015
